P10 Outdoor LED Panel

Product Description:

  1. The LED P10 outdoor full-color SMD LED display is designed for outdoor high-definition display; The full-color LED display is waterproof, dustproof, and can withstand IP67 pressure. It is stable and reliable.
  2. Surface-mount triple packaging technology uses a combination of red, green, and blue phosphors to produce up to 1.07 billion different colors. Each light-emitting unit includes three LED chips—one for red, green, and blue—arranged in a triangular pattern called an LED package.
  3. In order to support the high-definition video input, this product supports VGA, DVI, HDMI video signal input display.

Technical Details

Model NumberJL – Outdoor P10 LED Module
Brand NameJASIONLIGHT ManufacturerScreen Plainness<±1mm
Place of OriginGuangdong, ChinaMean Time Between Failures>10,000 Hours
Pixel PitchP10Life Span>100,000 Hours
Mini Viewing Distance10mDisplay Working Voltage
AC46~54HZ, 220V±15%/110V±15%
LED ConfigurationSMD3535Luminous Attenuation<3%
Module Resolution32×16 pixelsLeakage Current<3mA
Module Pixels512 pixelsIP GradeIP65
Module SizeL320mm*H160mm*T18.5Working Environment Temperature & Humidity
Temperature:-20 Celsius~+60 Celsius Humidity:10%~90% RH
Cabinet Size960mm*960mmMedia Available
Datasheet, Photo, EDA/CAD Models, Video
Pixel configurationSMD3in1, Full Color R/G/B 1,1,1FunctionSDK
Equilibrium Brightness7000cd/㎡ for outdoorControl Mode
Synchronous display with control PC by DVI
Driving Method1/4 scan or 1/2 scanSupport SoftwareWindows XP/W7/Vista
Refresh Rate≥1920 HzControl System
DVI video card + full color control card + fiber system( optional)
Changing Detection Frequency50-60HzMain Control System BrandNovastar, Linsn, Huidu, Colorlight
PerspectiveV140° V120°InterfaceStandard Ethernet
Dead Light Rate≤1%Transmission Distance
Multi mode fiber <500m, single mode fiber <30km, internet cable <100m
Power Waste700*1000 W/M2Warranty5 Years
Average Power Consumption300 W/M2Supplier TypeOriginal manufacturer, ODM, OEM
Gray Scale16-bit (281 trillion color) / 65,536 shades per primary colorLead Time25(or to be negotiated)
Display Color16MApplicationAdvertising, Outdoor /Indoor
Uninterrupted Working Hours≥72 hoursUse
Advertising Publish, Shopping Mall, Welcome Display, Exhibition Hall, Airport, Church, Sport, Event, Meeting, Rental, Stage, Car, Commercial, Wedding
Discrete Blind Spot Rate<1/10000Packaging DetailsKraft carton and wooden case
Continuous Blind Spot RateNoneSupply Ability5000 Piece/Pieces per Month
Blind Spot Rate<1/10000PortShenzhen

Your Expert LED Screen Supplier in China

  1. JASIONLED is your expert LED screen supplier in China. We have more than 20 years of experience in this field, which makes us one of the most reliable suppliers of LED screens. Our products include indoor and outdoor LED screens, portable led screens, led display walls and so on.
  2. JASIONLED has been certified by ISO9001:2008 Quality Management System Certification, ROSH Certification and CE Marking Certificate.
  3. We have our factory with an area of about 8,000 square meters. Our factory has advanced production lines and a group of high-level design engineers who can make the perfect products according to your requirements. With a strict quality control system and excellent customer service attitude, we can satisfy all your needs with high-quality products at competitive prices!
